MKE7 Firmware Update

Before starting the procedure description, it is important to understand the relationship between: To work the ECU needs in THIS SEQUENCE. Hardware and firmware are strictly related. Firmwares are made for a specific hardware. Example 1: On a YAMAHA YMERWSS or YMERKIT only the specific firmware will work. It is not possible to use a […]

Button Setup in SS NextGeneration

For existing applications , caming from FIM Supersport 600 , often there is an issue related to button setup . The Next Generation rules are moving on a direction to unify some parts , including left hand buttons . This is to have unified system to navigate through the DashBoard for the technical check . […]

MECAL updates from internet

Software upgrade is underway! The UPDATE FROM INTERNET BUTTON has been disabled! To download updates go on FILE and select WORKSPACE CREATE. The popup window shown below will appear. Choose download template from internet (an internet connection is needed). In the window, all available workspaces will be shown and are ALWAYS updated. The workspaces have […]

Engine Brake Trimmer (Fw 2.24 onwards)

What does it do? It modifies throttle position to modify engine brake. Rider side: Two buttons (monostable) + (plus) and – (minus). It can be set as + (plus) = more engine brake or as + (plus) = more throttle (less engine brake). This last solution is not recommended, +(plus) as + EB is easier […]

Gear Shift Trigger and Re-Arm threshold

In the Gear shift startegy tab the trigger and re arm values can be set. As a general rule the Trigger’s ABSOLUTE VALUE must be always higher than the re-arm value: Trigger: Amount of force (Nm) needed to activate the strategy Re-arm: Amount of force (Nm) needed to reactivate the strategy after a trigger Some […]

Sensors for Suspension

Reading the suspensions position could be easy , but in reality if You would like to have accurate measures , You should know how the sensor is made and how the ECU’s input is made . Usually ECU have many analog inputs , each one with different characteristics , with PULL UP ( to 5 […]

Supersport 2022 Schematics ( updated )

We just released the official schematic draws for some Supersport Next Generation ( DUCATI V2 and TRIUMPH 765 ) , this should be used as reference for motorbike used from 2022 World Championship , and National Championships that follow the FIM technical rules for Supersport Next Generation . Please consider that You should ever check […]

MKE5-7 Fixing

One of most importan and often difficult work to do is the ECU fixing . Lot of applications that use MKE5 and MKE7 need a proper installation , because of the ECU have internal IMU , and this is used for BIKE CRASH detection and for more advanced applications for LEAN and PITCH angle estimation […]

2D Data Recovery

Dowloading data from Stick Logger V2 ( from 2019 ) with old software ( before 2019 ) , You can have inconsistent data , because of data format changes . On following document You can read something about cause and solutions .

MKE7 Connector Tips

The design and manufacturing of a racing wiring loom is not easy, the most common problems coming from the wiring loom are often small details, but this makes the difference between winning or losing a championship. We are sure You can get some important tips from the document here below . You can download it […]
